LWP16/30, 20/40, 30/50, 40/70
SEPROP
69149000
SEPPE Lightweight Proppant is a low-density ceramic proppant designed for hydraulic fracturing applications where efficient transport, controlled particle size, crush resistance, and stable fracture conductivity are required. This lightweight grade is supplied under the SEPLITE LWP series and is suitable for projects requiring a ceramic alternative with lower density than intermediate-density or high-strength proppants.
▸ Lightweight Proppant is a lower-density ceramic proppant used to support fractures after hydraulic fracturing pressure is released.
▸ The product combines ceramic crush resistance with lower apparent and bulk density, helping improve proppant transport and placement compared with heavier ceramic grades.
▸ SEPPE Lightweight Proppant is designed for projects that require controlled mesh distribution, high sphericity and roundness, conductivity support, and lower-density ceramic performance.
▸ Low-Density Ceramic Design: Apparent density is approx. 2.70 g/cm³, absolute density is approx. 2.80 g/cm³, and bulk density is approx. 1.53 g/cm³.
▸ Controlled Shape Quality: Typical sphericity and roundness are 0.9 × 0.9 by Krumbein and Sloss methods, supporting stable proppant packing and fracture flow capacity.
▸ Crush Resistance: Crush-test data are available at 7,500 psi and 10,000 psi across common mesh sizes, supporting technical selection for moderate closure-stress applications.
▸ Conductivity & Permeability: Conductivity and permeability data are available across 16/30, 20/40, 30/50 and 40/70 sizes under different closure pressure points.
▸ Export Packaging: Standard packing is 1.5 MT polypropylene bags, with packaging and shipment arrangements available according to order requirements.
| Item | 16/30 | 20/40 | 30/50 | 40/70 |
|---|---|---|---|---|
| Average Diameter | 0.940 mm | 0.680 mm | 0.440 mm | 0.310 mm |
| Sphericity × Roundness | 0.9 × 0.9 | 0.9 × 0.9 | 0.9 × 0.9 | 0.9 × 0.9 |
| Apparent Density | 2.70 g/cm³ | 2.70 g/cm³ | 2.70 g/cm³ | 2.70 g/cm³ |
| Bulk Density | 1.53 g/cm³ | 1.53 g/cm³ | 1.53 g/cm³ | 1.53 g/cm³ |
| Crush Fines @ 7,500 psi | 7.5% | 3.3% | 2.4% | 2.0% |
| Crush Fines @ 10,000 psi | 9.6% | 5.9% | 4.7% | 3.9% |
▸ Hydraulic fracturing projects requiring lower-density ceramic proppant
▸ Oil and gas reservoirs where transport efficiency and conductivity support are important
▸ Applications requiring a ceramic alternative to conventional sand under suitable closure stress
▸ Projects requiring 16/30, 20/40, 30/50 or 40/70 lightweight proppant size selection
▸ Fracturing designs where crush resistance, particle shape, and conductivity retention are key selection factors
▸ Key quality checks include particle size analysis, sphericity, roundness, apparent density, absolute density, bulk density, crush resistance, chemical analysis, conductivity and permeability.
▸ Detailed batch control, COA, TDS data, retained samples and third-party inspection options are available on the Lightweight Proppant Quality Control System page.
▸ Standard packing is 1.5 MT polypropylene bags. Other packaging and loading arrangements can be discussed according to order requirements.
▸ SEPPE supports export packaging, container loading, batch identification and shipment documentation for bulk lightweight proppant orders.
▸ Selection should be based on closure stress, conductivity target, reservoir conditions, mesh size, pumping design and customer purchase specification.
▸ Common lightweight proppant sizes include 16/30, 20/40, 30/50 and 40/70. Final availability should be confirmed according to order requirements.
▸ Yes. SEPPE can provide TDS, particle size distribution, density, crush test data, conductivity and permeability information, packing details and batch inspection records.
▸ Yes. Third-party inspection or project-specific testing can be arranged according to customer requirements and purchase specification.
Contact SEPPE to discuss mesh size, closure stress, conductivity target, TDS data, samples, packaging and bulk pricing.
